Description
|
|
PART |
DESCRIPTION |
|
A |
UFA30061 |
KStrong® Deadweight Rooftop Non-penetrating Freestanding Counterweight System (Comprised of Parts B, C, & D) |
|
B |
UFA30061(01)SUB1 |
Set of 8 Casted Dead Weight Upper Plates |
|
C |
UFA30061(02)SUB2 |
Set of 4 Molded Dead Weight Bottom Plates with Locking Stud and Cotter Pin |
|
D |
UFA30061SUB3 |
Main Plate and Shock Assembly for the Deadweight Anchor Frame |
Key Features
DESIGN:
- Deadweight Rooftop Non-penetrating Freestanding Counterweight System is designed to be used as a anchorage point where structural anchors are not available for the users working near a potential fall hazard.
- Comes with polymer base plate to provide better grip and stability with the mating surface.
- Compatible with different roof surfaces as bitumin, asphalt and concrete.
- Equipped with a central shock absorbing post which deploys in the event of a fall.
- Anchor post can be used in different configurations to perform various activities including the following:
|
APPLICATION |
COUNTER WEIGHT |
NO. OF USERS |
|
Anchor Post for Fall Arrest |
882 lbs. (400kg) |
1 |
|
Suspension |
882 lbs. (400kg) |
1 |
|
Lifeline Intermediate |
1102 lbs. (500kg) |
1 |
MATERIAL:
Counter Weight and Cross Arm – Alloy Steel
Shock Absorbing Post – Stainless Steel
FINISH:
Counter Weight and Cross Arm – Powder Coated
Shock Absorbing Post – Electropolished / E-coated
SYSTEM STRENGTH:
12 kN
WEIGHT:
881.8 lbs. ± 0.02 lbs. (400kg ± 0.01kg)
RELEVANT STANDARD:
Meets or Exceeds EN 795:2012 Type E
