Description
Key Features
DESIGN:
- An anchor is designed to be fixed on a metal I-beam to install a horizontal lifeline
- The base has an adjustable opening to adapt to the type of beam section
- It is easy and quick to install with the help of a nut and bolt
- The post comes with a pre-installed steel anchor to make connections
WORKING LENGTH:
12 inches
COMPATIBLE WITH MININUM FLANGE WIDTH:
7.09” (150mm)
COMPATIBLE WITH MAXIMUM FLANGE WIDTH:
8.66” (220mm)
MATERIAL:
Alloy Steel
FINISH:
ED Coated Black / Powder Coated Black
SYSTEM STRENGTH:
23 kN.
WEIGHT:
18.96 lbs. ± 0.22 lbs. (8.60 kg ± 0.10 kg)
RELEVANT STANDARDS:
Meets or Exceeds ANSI / ASSE Z359.18-2017 Type A
Welding (Arc Flash)
