Standalone Counterweight Anchor Post (300KG)

Compare
SKU: AFA935865 Categories: ,
Description

Description

AFA935865-Standalone Counterweight Anchor Post (300KG)

Key Features

FEATURES:

  • The Counterweight Anchor has been designed to be used as an anchor post where it’s not possible to install posts on flat roof surfaces or the supporting structure below.
  • In-Built shock absorbing post to reduce the impact to user and structure
  • The anchor device is supplied with four rubber coated base weights to provide better grip on the roof
  • They must be in contact with the roof surface when it is fully assembled
  • Suitable to be used as part of a Fall Arrest system.
  • Suitable to use on flat surfaces up to a maximum of 5 degrees slope/pitch
  • Do not use if the roof surface has been contaminated by grease, oil or any other type of lubricant.
  • Simple and easy to assemble – 8 steel plates & 4 rubber base plates supplied
  • Suitable for 1 person

MATERIAL:

System including base plates : High Strength Alloy Steel
Finish : Powder Coated
Rubber Base : Rubber

WEIGHT:

Complete System : 316.5 kgs ± 0.10 kgs
Steel Base Plates : 25 kgs of each
Rubber Base Plates : 25 kgs of each

SYSTEM STRENGTH:

15kN

CONFORMS TO:

EN 795:2012 TYPE E
