Standalone Counterweight Anchor Post (300KG)

Description

AFA935865-Standalone Counterweight Anchor Post (300KG)

Key Features

The Counterweight Anchor has been designed to be used as an anchor post where it’s not possible to install posts on flat roof surfaces or the supporting structure below.
In-Built shock absorbing post to reduce the impact to user and structure
The anchor device is supplied with four rubber coated base weights to provide better grip on the roof
They must be in contact with the roof surface when it is fully assembled
Suitable to be used as part of a Fall Arrest system.
Suitable to use on flat surfaces up to a maximum of 5 degrees slope/pitch
Do not use if the roof surface has been contaminated by grease, oil or any other type of lubricant.
Simple and easy to assemble – 8 steel plates & 4 rubber base plates supplied
Suitable for 1 person
Suitable for Abseiling

System including base plates : High Strength Alloy Steel
Finish : Powder Coated
Rubber Base : Rubber

Complete System : 316.5 kgs ± 0.10 kgs
Steel Base Plates : 25 kgs of each
Rubber Base Plates : 25 kgs of each

15kN

EN 795:2012 TYPE E & TS16415:2013 Type E
