AFA930125-Duckboard Anchor with Wire Loop
Key Features
FEATURES:
- Simple, light and easy to be installed on a range of walkways, platforms and horizontal surfaces with a min. mesh grating size of 30mm x 30mm.
- Used with a fall arrester system, but can also be used as a restraint system.
- Anchorage wire rope sling with thimbled loop at one end as an attachment point.
- Openable top covers for ease of installation and inspection.
- Comes in 3 different lengths of wire rope slings (250 mm / 500 mm/750 mm).
- Supplied with an 8.5 m long cord to facilitate installation of the fall arrest
system.
MATERIAL:
Casing : Polymer with Aluminum Reinforced Plate
Anchor Sling : 4.8mm GI Wire
MINIMUM BREAKING STRENGTH:
15 kN
CONFORMS:
EN 795:2012 TYPE B & AS/NZS 5532:2013
WEIGHT:
AFA930125(250) : 2.31kgs. ± 0.020 kgs.
AFA930125(500) : 2.53 kgs. ± 0.020 kgs.
AFA930125(750) : 2.58 kgs. ± 0.020 kgs.
