KStrong, Unrivaled Safety
Description
Description
AFT710037-Quadpod Multifunction Rescue System
Key Features
FEATURES:
- Adjustable Height: Achieve a height range of 1.45m to 2.08m from ground level, catering to different requirements and working conditions.
- Minimum Height: Legs are spaced 1.1m apart at the foot point, promoting stability and balance.
- Maximum Height: Legs extend to 1.55m apart at the foot point, ensuring ample support even at greater elevations.
- Inner and Outer Sliding Mechanism: Easily customize the height by sliding the telescopic legs, providing flexibility in setup.
- Secure Locking Pins: Stainless steel cables attach the locking pins, offering added safety and reliability.
- Dual Pulley Configuration: Two pulley systems are included to simultaneously accommodate the wire rope of the mounted winch on one leg and the retrieval block on the other leg.
- Consists of pre-installed universal mounting attachments to easily mount the Winch and Retrieval Block when used with AFT710007UW Winch Bracket and AFT710007UR Retrieval Bracket.
MATERIAL:
Tripod Legs : Material – 6065 T5 Aluminum Alloy
Finish – Powder Coated & Anodized
Head : Material – Steel Alloy
Finish – ED Coated Black
Anchor Points : Material – Steel Alloy, Rated 23kN
Locking Pins : Material – Stainless Steel locking pin
Chain : Material – Alloy Steel Galvanized
MAXIMUM LOAD CAPACITY:
500kgs
CERTIFICATION:
EN 795: 2012 Type B, TS 16415:2013 Type B and ANSI Z359.18-2017
Type A (for upto 2 users)
HEIGHT:
1.45m to 2.08m
WEIGHT:
32.01 kg ± 0.10 Kgs
